40HP plate-changing water chiller, cooling through the compressor, no need to worry about cleaning the water tank, customized products, quality guaranteed.
Our company can specify the refrigerant, and the machine itself contains 6 major protection measures to help customers use the product more safely.
| Model | Product name | PQ-ZL40A(30Tons) |
| Power | Voltage | 3N/440V/60HZ |
| Power Input | KW | 38 |
| Cooling Capacity | Kcal/H | 105000 |
| KW | 112 | |
| Temperature Range | ℃ | 5℃~35℃（Below 0℃ Could be customized） |
| Refrigerant | Name | R407C |
| Control Method | Expansion Valve | |
| Compressor | Type | Hermetic Scroll Type |
| Brand | Inward | |
| Power(KW) | 7.5*4 | |
| Draught Fans | Air Volume（M³/H) | 51000 |
| Power（KW） | 0.66*6 | |
| Dimension Fans（MM） | 550*6 | |
| Heat Dissipation Ambient Temperature | ≤35℃ | |
| Condenser | Form | Efficient Brass Sets Coorrugated Aluminum Fin |
| 304 Steel Stainless Evaporate | Type | Plate Heat exchange (heat interchange) |
| Water Volume(L/Min) | 400 | |
| Inlet/Outlet (DN) | 65 | |
| Circulating Pump | Power(KW) | 4 |
| Convey Water（M） | 37 | |
| Brand | stainless steel pump | |
| Whole Machine | Weight（KG） | 1380 |
| Dimension（CM） | 2410*1830*1960 |
Priority is given to using R407 refrigerant, and the required refrigerant can also be added according to customer needs.
If you don't need a large cooling capacity, but if you need a more professional chiller, you can choose a 40HP plate-replacement chiller.
Can be used as an all-in-one hot and cold machine.
No water tank, use compressor to cool down, reduce accessories.
Not easily damaged and easy to clean.
Customized products, production time is about 10 days.
