PQ-ZL01A 1HP Air Cooled Chiller

Huizhou PengQiang, service-oriented, provide one-stop service, Ships within five business days.

The 1HP machine is suitable for cooling low-power products. It is small in size, does not take up space, and the internal space is easy to repair. The price is affordable, the production time is short, and the quality service is guaranteed.


pengqingzili

Specifications of PQ-ZL01A 1HP Air Cooled Chiller


ModelProduct namePQ-ZL01A
PowerVoltage1N/220V/50hz
Cooling CapacityKcal/H2500
KW2.8
Temperature Range5℃~35℃(Below 0℃ Could be customized)
RefrigerantNameR22(Or R134a/R407c)
Control MethodCapillary Tube
CompressorTypeHermetic Scroll Type or Piston Compressor
BrandGree
Power(KW)0.75
Draught FansAir Volume(M³/H)1000
Power(KW)0.15*1
Dimension Fans(MM)350*1
Heat Dissipation Ambient Temperature≤35℃
CondenserFormEfficient Brass Sets Coorrugated Aluminum Fin
EvaporateWater Volume(M³/H)0.51
Water Tank Volume(L)40
Inlet/Outlet (DN)20
Circulating PumpWater Flow40(L/min)
Power(KW)0.37
Convey Water(M)18
BrandAuyuan
Whole MachineWeight(KG)70
Dimension(CM)85*52*80


Features of PQ-ZL01A 1HP Air Cooled Chiller

01

Air cooled 1HP portable & packaged chiller.


02

No water tower required.

03

Easy intallation, connected with pipe and power on is ok for working.


04

Reliable and energy efficient scroll compressors.


05

Stainless Steel Inlet and Outlet.


06

TV-fin ling condenser, increase the heat dissipation area,heat dissipation effect is better.


07

External rotor fan,1300 RPM strong windlarge air volume small vibration, fast heat dissipation.


08

High efficiency, low energy consumption, stable and durable.can be customized according to customer demands for different power and stainless steel water pumps.different needs to choose different water pumps.


09

Safe for user.


10

Punp control panel, (low failure rate/good stability/durable/easy maintenance) Schneider electric accessories, international export chiller,standard safety protection device.


11

Small industrial chiller, small size, save space.


Contact Us for Customizable Industrial Chiller!
One-stop refrigeration service, chiller source factory, free customized solution service~ Contact us today for your premium and relaible industrial chiller.
