Huizhou PengQiang, service-oriented, provide one-stop service, Ships within Five business days.
Dedicated to injection blowing, extrusion granulation, thermal plastic machining, non-cutting casting surface treatment, laser technology, welding, plastic molding, etc. Cooling; electroplating oxidation equipment cooling plastics, electronic manufacturing, electroplating pharmaceutical chemicals, ultrasonic cooling Refrigeration and cooling in chemical industries such as printing and printing; speed up product cycle and improve product quality.
| Model | Product name | PQ-ZL05W |
| Power | Voltage | 3N/380V 50HZ |
| Cooling Capacity | Kcal/H | 20640 |
| KW | 24 | |
| Temperature Range | ℃ | 5℃~35℃（Below 0℃ Could be customized） |
| Refrigerant | Name | R22(Or R134a/R407c) |
| Control Method | Capillary Tube | |
| Compressor | Type | Hermetic Scroll Type or Piston Compressor |
| Brand | Panasonic | |
| Power(KW) | 6 | |
| Condenser | Form | Straight Tube |
| Evaporate | Water Volume(M³/H) | 4.82 |
| Water Tank Volume(L) | 120 | |
| Inlet/Outlet (DN) | 40 | |
| Circulating Pump | Water Flow | 150(L/Min) |
| Power(KW) | 1.1 | |
| Convey Water（M） | 20 | |
| Brand | Auyuan | |
| Whole Machine | Weight（KG） | 300 |
| Dimension（CM） | 130*60*136 |
Refrigeration capacity up to 24Kw.
The water tank capacity of 8HP machine is upgraded to 150(L/Min).
The operation is simple and easy to learn: 1. Press “Pump” 2. Press “Compressor 1” to start.
Large-capacity water storage tank is durable and refuses to leak.
Open waterway systems such as water/buckets/pools need to customize self-priming pumps.
Adopt brand high and low pressure oil gauge digital display is clear, the data is accurate.
LCD display interface, display/set cold water temperature, support Chinese and English interface switching.
Bass noise, stable operation.
Need water tower.
