Huizhou PengQiang, service-oriented, provide one-stop service, Ships within Ten business days.
The air-cooled screw chiller adopts an internationally renowned screw compressor, equipped with high-quality and high-efficiency copper tubes to make a condenser, an evaporator and world-famous brand control components, so that the unit has small size, low noise, large energy, long life, and easy operation. Advantages, its beautiful and exquisite shape design and reliable and stable high-efficiency quality are outstanding among similar products!
| Model | Product name | PQ-ZL25A(20Tons) |
| Power | Voltage | 3N/380V/50HZ |
| Power Input | KW | 22 |
| Cooling Capacity | Kcal/H | 62500 |
| KW | 70.5 | |
| Temperature Range | ℃ | 5℃~35℃（Below 0℃ Could be customized） |
| Refrigerant | Name | R407C |
| Control Method | Expansion Valve | |
| Compressor | Type | Semi-Hermetic Screw Compressor |
| Brand | Hanbell | |
| Start Model | Y-△start | |
| Capacity Control(%) | 0-25-50-75-100 | |
| Power(KW) | 18.75 | |
| Draught Fans | Air Volume（M³/H) | 26640 |
| Power（KW） | 0.9*4 | |
| Dimension Fans（MM） | 630*2 | |
| Heat Dissipation Ambient Temperature | ≤35℃ | |
| Condenser | Form | Efficient Brass Sets Coorrugated Aluminum Fin |
| Tube and Shell Evaporate | Type | Shell and Tube |
| Water Volume(L/Min) | 200 | |
| Inlet/Outlet (DN) | 50 | |
| Circulating Pump | Power(KW) | 2.2 |
| Convey Water（M） | 18 | |
| Brand | Auyuan | |
| Whole Machine | Weight（KG） | 880 |
| Dimension（CM） | 2010*1780*1100 |
Air water cooled 25HP 20ton central chiller.
For large equipment cooling.
Brand compressor silent operation.
Cooling capacity up to 62500Kcal/H.
V- tvpeallred copper condenser.
External rotor fan.
Emerson filter.
HD PLC touch screen sensitive touch control.
Water Tank Volume 200L.
Modular design allows up to six multiple circuits to be linked together with a common control system.
